Megamo RAISE 05 SH12 (23)

~~1 kr~~
1 kr

TECHNICAL INFORMATION FramesetFrameCarbon Advanced Composite frame, Full Internal Cable Routing, Flat mount disc 12x142ForkCarbon Advanced Composite fork,

Unfortunately, the product is out of stock. But contact us and we will if we can get it for you soon.

Article Number: 1297

Information
Reviews

TECHNICAL INFORMATION

Frameset

	Frame	Carbon Advanced Composite frame, Full Internal Cable Routing, Flat mount disc 12x142
	Fork	Carbon Advanced Composite fork, Full Internal Cable Routing, Flat mount disc 12x100
	Headset	Totally Internal Cable routing

Drivetrain

	Rear Derailleur	Shimano Ultegra Di2 R8150 12s
	Derailleur	Shimano Ultegra Di2 R8150 12s
	Shifters	Shimano Ultegra Di2 R8150 12s
	Crankset	Shimano Ultegra Di2 R8100 12s 52-36T
	Cassette	Shimano Ultegra Di2 R8100 12s 11-30T

Brakes

Shimano Ultegra Di2 R8170 12s Hydraulic Disc

Wheels

	Tires	Vittoria Rubino Pro IV 28-622 TLR full black G2.0
	Hubs	Vision Team 35 Disc 12x100 / 12x142
	Wheels	Vision Team 35 Disc

Components

	Handlebar	Carbon Full Integratted Internal Cable Routing: 90/400 (XS,S), 100/400 (S,M), 110/420 (M,L), 120/440 (L,XL)
	Seatpost	Aerodinamic Advanced Carbon Seat Post
	Seat	Selle Italia Novus Boost Evo Superflow

We reserve the right to modify the information on the website without prior notice, including specifications, models, colors and materials.

GEOMETRY RAISE 05 SH12 (23)

		XS	S	M	L	XL
A	T/T	507	523	541	559	576
B	C/S	405	405	405	405	405
C	S/T	422	453	473	499	525
D	H/T	103	116	135	156	176
E	REACH	357	369	381	393	405
F	STACK	505	522	541	560	580
G	BB HEIGHT	270	270	270	270	270
H	FRONT ANGLE	70,5º	72º	72º	72º	72º
I	REAR ANGLE	73,5º	73,5º	73,5º	73,5º	73,5º

HANDLEBAR AND STEM INTEGRATED:

	XS	S	M	L	XL
90/400			-	-	-
100/400	-			-	-
110/420	-	-			-
120/440	-	-	-

FIT GUIDE
X-SMALL	158 - 168
SMALL	165 - 172
MEDIUM	170 - 182
LARGE	182 - 190
X-LARGE	188 - 210
