Megamo RAISE AXS 07 (23)

~~1 kr~~
1 kr

TECHNICAL INFORMATION FramesetFrameCarbon Advanced Composite frame, Full Internal Cable Routing, Flat Mount Disc Brakes 12x142ForkCarbon Advanced Composite

Unfortunately, the product is out of stock. But contact us and we will if we can get it for you soon.

Article Number: 1300

Information
Reviews

TECHNICAL INFORMATION

Frameset

	Frame	Carbon Advanced Composite frame, Full Internal Cable Routing, Flat Mount Disc Brakes 12x142
	Fork	Carbon Advanced Composite fork, Full Internal Cable Routing, Flat Mount Disc Brakes 12x100
	Headset	Integrated Internal Routing, 3 positions, 3 different heights

Drivetrain

	Rear Derailleur	Sram Force AXS 12s
	Derailleur	Sram Force AXS 12s
	Shifters	Sram Force AXS 12s
	Crankset	Sram Force AXS 12s 48-35 Powermeter
	Cassette	Sram Force AXS 12s 10-33t

Brakes

Sram Force AXS 12s

Wheels

	Tires	Vittoria Corsa Graphene 2.0 Skinwall
	Hubs	Vision Team 30 Disc
	Wheels	Vision Team 30 Disc

Components

	Handlebar	MEGAMO FOV COMPACT
	Stem	Intergated internal routing
	Seatpost	Megamo 27,2mm
	Seat	Selle San Marco Shortfit Dynamic Wide Manganese Carbon Fiber Reinforced 250 x 144mm

We reserve the right to modify the information on the website without prior notice, including specifications, models, colors and materials.

GEOMETRY RAISE AXS 07 (23)

		XS	S	M	L	XL
A	T/T	507	523	541	559	576
B	C/S	405	405	405	405	405
C	S/T	422	453	473	499	525
D	H/T	103	116	135	156	176
E	REACH	357	369	381	393	405
F	STACK	505	522	541	560	580
G	BB HEIGHT	270	270	270	270	270
H	FRONT ANGLE	70,5º	72º	72º	72º	72º
I	REAR ANGLE	73,5º	73,5º	73,5º	73,5º	73,5º

HANDLEBAR AND STEM INTEGRATED:

	XS	S	M	L	XL
90/400			-	-	-
100/400	-			-	-
110/420	-	-			-
120/440	-	-	-

FIT GUIDE
X-SMALL	158 - 168
SMALL	165 - 172
MEDIUM	170 - 182
LARGE	182 - 190
X-LARGE	188 - 210
